Foxeer Reaper FC AIO V2 F745 45A BLS 2-6S FPV Flight Controller

Foxeer Reaper FC AIO V2 F745 45A BLS 2-6S FPV Flight Controller

Product description

Foxeer Reaper FC AIO V2 F745 45A BLS 2-6S FPV Flight Controller

Plug & Play with Foxeer cameras for direct remote control

• Model: FOXEER Reaper AIO V2

• CPU: STM32F745

• Power supply: 2~6S Lipo(8.4~25.2V)

• BEC output: DC5V/2.5A

• OSD: BF OSD

• Black box: 16M Flash memory

• UART: 5 set

• USB: Micro USB

• Fireware BF:FOXE-FOXEERF745V2_AIO

• DJI/Vista connector: Supported 7pin

• Size: 32.5X32.5mm

• Mounting hole: 25.5X25.5mm,Φ3mm/M2

• Weight (g): 8.6g

• Working temperature: -20℃ ~ +55℃

• Working humidity: 20～95%

• Storage temperature: -20℃ ~ +70℃

• Package contains

• Bluejay firmware: G-H-30-96-v0.16/ BLS:G-H-30 16.7
• Continuous/burst current: 45A x 4/ 50A x 4
• Input voltage: 2~6S Lipo(8.4~25.2V)
• Telemetry: No
• ESC Programming: Bluejay (standard)/BLHeli-S optional
• Stick programming: Supported
• Current sensor: Supported
• Current scale: 100
• Input signal: Dshot300/600

• Contents
• Foxeer Reaper FC AIO V2 F745 45A BLS 2-6S FPV Flight Controller
• 1x AIO, rubber columns
• 1x XT30 cable
• 1x Vista cable
