GEPRC Tern-LR40 Analog Long Range Drone FPV PNP

GEPRC Tern-LR40 Analog Long Range Drone FPV PNP

Product description

Welcome to the GEPRC family! We proudly present our newest family member: the Tern-LR40. This 4-inch long range FPV copter offers excellent performance and reliability. Its DC structure, carefully designed to be lightweight with parts made of aerospace-grade 7075 aluminum, makes it not only light but also stable.

Equipped with the Taker G4 45A AIO flight controller, it offers higher computing power and redundancy. The top-mounted fixed GPS avoids interference from electromagnetic influences on the flight, and the rescue function is more stable as a result. A silicone camera shock absorption mat prevents high-frequency flicker on the O3 camera.

The Tern-LR40 glides freely through the blue sky like a bird with outstretched wings, without being restricted. Choosing this copter means not only a high-quality flight, but also an artistic journey.

Features:

• New lightweight design, under 249g.
• Advanced GPS fixation to avoid sources of interference.
• DC structure for clear line of sight during flight, ideal for straight aerial shots.
• Installation of the BB ring to adjust the low voltage alarm of the battery.
• Use of the GEP-M10nano GPS for faster satellite search and more stable rescue modes.
• Compatible GoPro mount for enhanced creative recording possibilities.

Specifications

• Model: Tern-LR40
• Frame: Tern-LR40 Frame
• Top plate: 1.5mm
• Middle plate: 2.0mm
• Bottom plate: 1.5mm
• Arm thickness: 3.5mm
• FC: Taker G4 45A AIO
• MCU: STM32G473CEU6
• Gyro: ICM 42688-P
• OSD: Betaflight OSD w/AT7456E
• ESC: 32Bit 45A
• VTX: RAD mini
• Camera: Caddx Ratel2
• Antenna: GEPRC Peano 5.8G RHCP UFL
• Connector: XT30
• Motors: GEP-SPEEDX2 1404 3000KV
• Propeller: HQProp T4X2.5Grey (2CW+2CCW)
• Weight Tern-LR40 Analog ELRS24 Version: 159g±5g
• Receiver: PNP
• Recommended battery: LiPo 4S 660mAh-850mAh/18650 3000mAh
• Flight time: 10-25min
