iFlight Nazgul 5 HD Caddx Polar Digital FPV Copter 6S Frsky XM+

iFlight Nazgul 5 HD Caddx Polar Digital FPV Copter 6S Frsky XM+

Product description

iFlight Nazgul 5 HD Caddx Polar Digital FPV Copter 6S Frsky XM+

HIGHLIGHTS:

• 5mm arm design for more durability
• Easily replaceable arms
• LED illuminated logo
• XING-E 2207 motors and NAZGUL 5140 propeller
• 5" version also fits 5.1" propellers
• Popular True-X configuration
• TPU crash guards
• Fits both 30.5x and 20x stacks

Nazgul5(XL5 V5) Frame Specifications:

• SucceX-E F7 45A Flight stack
• XING-E 2207 FPV motor （6S 1800kv / 4S 2750kv)
• Wheelbase: 240mm*240mm
• Body size: 170*170mm
• Propeller size: 5 inch /5.1 inch
• FC pattern: 30.5*30.5/20*20 mm
• FPV cam pitch: 19mm
• Weight: 400.8g (without battery)

Nazgul5 HD Quad BNF Included Components and Parts

• Pre-built and tested quadcopter
• 1x Nazgul5(XL5 V5) frame
• 1x Caddx Polar Vista Digital HD System Kit
• 1x Albatross LHCP RP-SMA 5.8g Antenna
• 2sets x Nazgul 5 inch 3-Blades (set of 4 - color may vary)
• 1x 20*200mm microfiber PU leather battery strap (color may vary)
• 1x 20*250mm microfiber PU leather battery strap (color may vary)

FC // SucceX-E F7 flight controller

• MCU: STM32F22RET6 216MHz
• Gyro: 20689
• Baro: DSP310 (Barometer can only be used with Betaflight 4.3.0 and higher)
• OSD: IFLIGHT OSD （AT7456E）
• BEC: 5V 2.5A
• BlackBox: 16MB
• Uart: 4*UART(UART1、UART2、UART4、UART5)
• UART1 for VTX HD（for 4-6S Vista，for 4S DJI Air Unit）/AnalogTelemetry
• UART2 for receiver
• UART4 for Free
• UART5 for ESC telemetry
• 4×Dshot/PWM outputs
• Smartaudio & IRC Tramp VTX protocol supported
• WS2812 LED Strip: Yes
• Bepper: Yes
• Firmware: IFLIGHT_SUCCEX_E_F7
• Outer size: 36*36mm / 30.5*30.5/φ4 mount
• Weight: 6.9g

ESC // SucceX-E 45A 2-6S BLHeli_S 4-in-1 ESC

• Dimensions: 40*43mm
• Mounting holes: 30.5*30.5mm/Φ3mm
• Weight: 14.4g
• Supports 2-6S Lipo input
• STM32F051 MCU, 48Mhz Runs with BLHELI 16.X firmware
• Current sensor: YES
• BEC: NO
• Supports: DShot150/300/600/1200/MultiShot/OneShot etc.
• Target: G-H-30 BLS 16.7

The product pictures may differ from the product
