Lumenier LUX Mini F7 FC Flight Controller

The Lumenier LUX MINI F7 Ultimate Flight Controller is the next generation of the popular Lumenier LUX flight controller series. It uses a powerful F7 processor along with top-notch hardware. Unleash the capabilities of your FPV racing quadcopter with the Lumenier LUX MINI F7 flight controller. This MINI LUX F7 comes in a small 20x20 form factor and weighs only 5g! Don't let the size of this flight controller fool you, it is packed with features and works with both micro and full size drones.

The MINI LUX F7 builds on the best features of its predecessors and further improves the hardware components and layout. You get a whopping 6 dedicated UART ports with built-in inversion for peripherals, along with built-in 128Mbit 16MB flash memory for black box recording. It includes an integrated BetaFlight OSD that lets you easily view important information like battery voltage, flight time, alerts, RSSI, smart audio, and more on your FPV display.

Have you ever participated in an FPV race where you need to plug in your quad but don't want to send an FPV signal to get your friends out of the air? Or how about when you crash and need to save your VTX from burning in the hot sun? With the LUX F7, you can turn your VTX on or off with a switch on your radio! The LUX MINI F7 features a filtered LC VBAT pad to power the VTX and an integrated 5V 3A regulator to power the camera, Rx and LEDs simultaneously. Using the PINIO resource, you can assign this pad to a switch on your radio to remotely control the power source for your video transmitter.

The Lumenier LUX MINI F7 supports all common accessories such as Beeer, camera control, Smart Audio / Tramp VTX control, PWM outputs and I2C connection.

Features

• MCU: 216MHz STM32F722RET6
• IMU: MPU6000
• OSD: AB7456
• Blackbox: 128Mbit / 16MByte
• Built-in anti-vibration silicone grommets
• 6x Uarts with built-in inversion
• 1x Softserial supported
• 1x I2C
• 1x SH1.0_8pin connector (Vbat/G/Curr/TLM/S1/S2/S3/S4)
• Vbat filtered output for VTX
• Camera control
• Smartaudio & Tramp VTX protocol support (S/A UART 5 TX)
• WS2812 Led Strip support
• Beeper solder pad
• Input: 6~36V (2~8S LiPo)
• BEC: 5V 3A Cont.
• LDO 3.3V: Max.200mA

Specifications

• High quality gold plated circuit board
• Micro USB connector for programming
• Dimensions: 28x28x6mm (including USB in height)
• Mounting holes: 20mm square to the center of the holes
• Weight: 5g
