Multiplex Power Peak Twin EQ-BID 1000W

Multiplex Power Peak Twin EQ-BID 1000W

Product description

12V 2-loader with max 2x 20A

The ultimate 1000 W charge station for the professional modeller
• 1000 W charging station with equalizer function and BID system
• 2 x 500 watts output with up to 20 A charge current, input voltage 11-28 V DC
• The Mega-Power charger with short charging time

features:
• BID system (Battery Identification system)
• 2 x temperature sensor input (10-60 ° C)
• 2 x 20 internal battery data memories
• 128 x 64 pixel blue backlit LCD display
• 10 melodies (selectable for each channel)

Technical specifications:
Input voltage: 11-28 V
Charging power: 1000 W (2 x 500 W)
Cell count LiIo / LiPo / LiFe: 1 - 7
Number of NiCd / NiMH:: 1 - 18
Cell count PB / lead: 1 - 12
Charging current: 0,1 - 20 A
Discharge current: 0,1 - 10 A (max 50 W).
Equalizer current: 250 mA
Charging Ports: 2
Dimensions: 170 x 175 x 60 mm
Weight approx .: 1220 g

Delivery:
Loaders POWER PEAK Twin
2 x equalizer adapter XH
2 x equalizer adapter TP
2 x Equalizer Adapter PQ
1 x Temperature Sensor
2 x BID-CHIP with cable
