Product description

The TBS M10 GPS Glonass is a small GPS device that works directly with Betaflight to provide you with accurate position data of your drone. It provides exactly the support you need when flying over long distances. Whether you need to activate Betaflight Rescue Mode or Return to Home Direction (RTH) or just the coordinates, this GPS device gives you an added sense of security and functionality when flying. With a state-of-the-art u-blox chipset, this module offers impressive performance and accuracy for a variety of applications.

Advanced chipset: The u-blox UBX-M10050 uses the advanced u-blox chipset for reliable and accurate positioning.

Configuration memory: With a flash memory for storing configurations, the module allows easy customization to your requirements.

Wide range of frequencies: Coverage of L1 (1575.42MHz), L2 (1561.10MHZ) and L3 (1602.00MHZ) frequencies for precise signal tracking.

Flexible baud rate: With a variable baud rate from 4800bps to 921600bps, 38400bps as standard, for optimum data transmission.

Fast positioning: Impressive sensitivity of -166dBm in tracking mode enables fast and accurate positioning.

Specifications

• Chipset: u-blox UBX-M10050
• Frequency: L1 (1575.42MHz), L2 (1561.10MHZ), L3 (1602.00MHZ)
• Baud rate: 4800bps-921600bps, standard 38400bps
• Cold start time: 26 seconds on average
• Warm-up time: 24 seconds on average
• Hot start time: 1 second on average
• Accuracy: Horizontal position autonomous <2m average | SBAS <2.0m average | Time pulse signal: RMS 30 ns
• Maximum altitude: 50000m
• Maximum speed: 500 m/s
• Maximum acceleration: ≦ 4G
• Update rate: 0.25Hz-18Hz, 1Hz by default
• Size: 18 x 18 x 6.1 mm
• Weight: 4.9g
• Input voltage: 5V
